QT 框架搭建，用最原始的方法实现简单的塔防游戏 | 原力计划
#ifndef MAINWINDOW_H
#define MAINWINDOW_H
#include <QWidget>
#include <QPainter> //画家
#include <QMouseEvent> //鼠标事件
#include <Qtimer> //定时器
#include "defensetowerpit.h" //防御塔坑类
#include "selectionbox.h" //选择框类
#include "defetowerparent.h" //防御塔父类
#include "monster.h" //怪物类
#include <QLabel>
class MainWindow : public QWidget
{
// Q_OBJECT
private:
QVector<DefenseTowerPit*> TowerPitVec; //防御塔坑数组
SelectionBox* SelBox = new SelectionBox("C:/Users/ASUS/Desktop/image/选择框.png"); //选择框类
QVector<DefeTowerParent*> DefeTowerVec; //重要防御塔父类数组
QVector<Monster*> MonsterVec; //怪物数组
void paintEvent(QPaintEvent *); //绘图事件
void mousePressEvent(QMouseEvent *); //鼠标点击事件
// void mouseMoveEvent(QMouseEvent *); //鼠标移动事件
void DrawMapArr(QPainter&); //用于画出地图函数
void DrawSelectionBox(QPainter&); //用于画出选择框
void DrawDefenseTower(QPainter&); //画出防御塔
void DrawMonster(QPainter&); //画出怪物
void DrawRangeAndUpgrade(QPainter&); //画出防御塔攻击范围和升级按钮
void DrawExplosion(QPainter&); //画出爆炸效果
int DisplayRangeX, DisplayRangeY; //用于记录显示范围的防御塔的坐标
bool DisplayRange = false; //用于显示防御塔攻击范围
struct ExploStr //爆炸效果结构
{
CoorStr coor; //记录爆炸效果的坐标
int index = 1; //记录要显示的图片文件的序号
int ExplRangeWidth; //爆炸效果宽高
int ExplRangeHeight;
//爆炸效果需要初始化坐标、效果宽高
ExploStr(CoorStr fcoor, int width, int height) : coor(fcoor), ExplRangeWidth(width), ExplRangeHeight(height) {}
};
QVector<ExploStr*> ExploEffectCoor; //爆炸效果坐标数组
int money = 1200; //记录金钱
QLabel *moneylable = new QLabel(this); //显示金钱标签控件
inline bool DeductionMoney(int); //判断金钱是否足够并刷新标签
int life = 10; //生命数量
int counter = 0; //用于产生怪物的计数器
const int RewardMoney = 26; //每次击败怪物获得的金钱数量
CoorStr *homecoor = new CoorStr(0, 0); //记录家的坐标，从地图中自动获取
void IrodMonsProgDefa(CoorStr**, CoorStr**, CoorStr*, int*, QLabel*); //预设两条路产生怪物方案函数
const int LevelNumber; //标识关卡
bool DisplayAllRange = false; //标识是否显示所有防御塔的攻击范围
public:
MainWindow(int); //构造
~MainWindow();
};
#endif //MAINWINDOW_H
#include "mainwindow.h"
#include <QDebug>
#include "globalstruct.h" //选择框按钮全局结构
#include <cmath> //数学
#include "greenturret.h" //绿色防御塔类
#include "fireturret.h" //火防御塔类
#include "lightturret.h" //光炮防御塔类
#include "bigturret.h" //大炮防御塔类
#include <QPushButton>
//鼠标点击区域宏
#define MouClickRegion(X, Width, Y, Height) \
(ev->x() >= (X) && ev->x() <= (X) + (Width) && \
ev->y() >= (Y) && ev->y() <= (Y) + (Height))
//计算两点之间距离宏
#define DistBetPoints(X1, Y1, X2, Y2) \
abs(sqrt((((X1) - (X2)) * ((X1) - (X2))) + (((Y1) - (Y2)) * ((Y1) - (Y2)))))
//用于方便通过格子确定路径点坐标
#define X40(X, Y) ((X) - 1) * 40 + 10, ((Y) - 1) * 40 + 10
//插入怪物 路径点数组名、怪物初始坐标、怪物编号
#define InsterMonster(PathNum, StaCoorNum, MonsterId) \
MonsterVec.push_back(new Monster(pointarr[PathNum], PathLength[PathNum], X40(staco[StaCoorNum].x, staco[StaCoorNum].y), MonsterId));
//判断金钱是否足够并刷新标签
inline bool MainWindow::DeductionMoney(int money)
{
if (this->money - money < 0) return true; //判断金钱是否足够
this->money -= money; //扣除金钱
moneylable->setText(QString("金钱：%1").arg(this->money)); //刷新标签文本
return false;
}
//构造
MainWindow::MainWindow(int LevelNumber) : LevelNumber(LevelNumber)
{
//设置固定窗口大小
setFixedSize(1040, 640);
//设置标题
setWindowTitle("游戏界面");
//提示胜利标签
QLabel *victorylable = new QLabel(this);
victorylable->move(176, 180);
victorylable->setFont(QFont("楷体", 110));
victorylable->setText(QString("游戏胜利"));
victorylable->hide();
QTimer* timer2 = new QTimer(this); //用于插入怪物定时器
timer2->start(2000);
connect(timer2,&QTimer::timeout,[=]()
{
//根据关卡编号确定执行怪物的路径方案
switch (LevelNumber)
{
case 0:
{
//设置路径点
CoorStr* Waypointarr1[] = {new CoorStr(X40(8, 6)/*X40是两个参数，为X坐标和Y坐标*/), new CoorStr(X40(2, 6)), new CoorStr(X40(2, 13)), new CoorStr(X40(19, 13)), new CoorStr(X40(19, 9)), new CoorStr(homecoor->x, homecoor->y)};
CoorStr* Waypointarr2[] = {new CoorStr(X40(20, 5)), new CoorStr(X40(14, 5)), new CoorStr(X40(14, 9)), new CoorStr(X40(8, 9)), new CoorStr(X40(8, 6)), new CoorStr(X40(2, 6)),
new CoorStr(X40(2, 13)), new CoorStr(X40(19, 13)), new CoorStr(X40(19, 9)), new CoorStr(homecoor->x, homecoor->y)}; //最后的路径点设为家
//怪物的四个起始点
CoorStr staco[] = {CoorStr(8, 0), CoorStr(20, 0), CoorStr(8, -1), CoorStr(20, -1)};
//每条路径的结点个数
int PathLength[] = {sizeof(Waypointarr1)/sizeof(CoorStr*), sizeof(Waypointarr1)/sizeof(CoorStr*)};
IrodMonsProgDefa(Waypointarr1, Waypointarr2, staco, PathLength, victorylable); //使用预设的两条路产生怪物方案
break;
}
case 1:
{
//设置路径点
CoorStr* Waypointarr1[] = {new CoorStr(X40(4, 8)), new CoorStr(X40(20, 8)), new CoorStr(X40(20, 13)), new CoorStr(X40(6, 13)), new CoorStr(homecoor->x, homecoor->y)};
CoorStr* Waypointarr2[] = {new CoorStr(X40(11, 8)), new CoorStr(X40(20, 8)), new CoorStr(X40(20, 13)), new CoorStr(X40(6, 13)), new CoorStr(homecoor->x, homecoor->y)};
//怪物的四个起始点
CoorStr staco[] = {CoorStr(4, 0), CoorStr(11, 0), CoorStr(4, -1), CoorStr(11, -1)};
//每条路径的结点个数
int PathLength[] = {sizeof(Waypointarr1)/sizeof(CoorStr*), sizeof(Waypointarr1)/sizeof(CoorStr*)};
IrodMonsProgDefa(Waypointarr1, Waypointarr2, staco, PathLength, victorylable); //使用预设的两条路产生怪物方案
break;
}
case 2:
{
//设置路径点
CoorStr* Waypointarr1[] = {new CoorStr(X40(12, 9)), new CoorStr(X40(8, 9)), new CoorStr(X40(8, 0)), new CoorStr(homecoor->x, homecoor->y)};
CoorStr* Waypointarr2[] = {new CoorStr(X40(12, 9)), new CoorStr(X40(16, 9)), new CoorStr(X40(16, 0)), new CoorStr(homecoor->x, homecoor->y)};
//怪物的四个起始点
CoorStr staco[] = {CoorStr(12, 16), CoorStr(12, 16), CoorStr(12, 17), CoorStr(12, 18)};
//每条路径的结点个数
int PathLength[] = {sizeof(Waypointarr1)/sizeof(CoorStr*), sizeof(Waypointarr1)/sizeof(CoorStr*)};
IrodMonsProgDefa(Waypointarr1, Waypointarr2, staco, PathLength, victorylable); //使用预设的两条路的产生怪物方案
break;
}
}
});
// setMouseTracking(true);
//显示防御塔范围按钮
QPushButton* disranpush = new QPushButton(this);
disranpush->setStyleSheet("color:black");
disranpush->setGeometry(20,160, 150, 45);
disranpush->setFont(QFont("微软雅黑", 12));
disranpush->setText("显示全部范围");
connect(disranpush,&QPushButton::clicked,[=]()
{//通过改变标识令防御塔攻击范围显示或关闭
if (DisplayAllRange)
{
DisplayAllRange = false;
disranpush->setText("显示全部范围");
}
else
{
DisplayAllRange = true;
disranpush->setText("隐藏全部范围");
};
update();
});
//金钱标签
moneylable->move(20, 40); //位置
setStyleSheet("color:white"); //设置颜色
moneylable->setFont(QFont("微软雅黑", 24)); //设置金钱标签属性
moneylable->setText(QString("金钱：%1").arg(money)); //显示金钱信息
//生命值标签
QLabel *lifelable = new QLabel(this);
lifelable->setGeometry(20, 100, 220, 40); //设置控件位置和大小
lifelable->setFont(QFont("微软雅黑", 24));
lifelable->setText(QString("生命：%1").arg(life));
//定时器每时每刻执行防御塔父类数组的活动函数
QTimer* timer = new QTimer(this);
timer->start(120);
connect(timer,&QTimer::timeout,[=]()
{
//防御塔寻找目标怪物的规律：找到最后一个怪物作为目标，目标丢失后找再继续找最后一个目标
for (auto defei : DefeTowerVec) //遍历防御塔
{
if (!defei->GetAimsMonster()) //目标怪物为空时从后往前遍历怪物数组寻找目标怪物
{
for(int i = MonsterVec.size() - 1; i >= 0; i--)
//这里以防御塔中心店和怪物中心点判断
if (DistBetPoints(defei->GetUpLeftX() + 40, defei->GetUpLeftY() + 40,
MonsterVec.at(i)->GetX() + (MonsterVec.at(i)->GetWidth() >> 1),
MonsterVec.at(i)->GetY() + (MonsterVec.at(i)->GetHeight() >> 1)) <= defei->GetRange())
{
defei->SetAimsMonster(MonsterVec.at(i)); //设置防御塔的目标怪物
break; //找到后跳出循环
}
}
else //当前防御塔拥有目标且怪物在防御塔范围之内时时攻击怪物
if (DistBetPoints(defei->GetUpLeftX() + 40, defei->GetUpLeftY() + 40,
defei->GetAimsMonster()->GetX() + (defei->GetAimsMonster()->GetWidth() >> 1),
defei->GetAimsMonster()->GetY() + (defei->GetAimsMonster()->GetHeight() >> 1)) <= defei->GetRange())
{
//根据每个防御塔的目标怪物计算旋转角度
defei->SetRotatAngle(
atan2
(
defei->GetAimsMonster()->GetY()/* + (defei->GetAimsMonster()->GetHeight() >> 1)*/ - defei->GetUpLeftY() + 40,
defei->GetAimsMonster()->GetX()/* + (defei->GetAimsMonster()->GetWidth() >> 1)*/ - defei->GetUpLeftX()
) * 180 / 3.1415 );
defei->InterBullet(); //拥有目标时一直创建子弹
}
//每次循环都判断目标怪物距离防御塔的距离，写在上面可能会不太好
if (defei->GetAimsMonster()) //目标怪物不为空
if (DistBetPoints(defei->GetUpLeftX() + 40, defei->GetUpLeftY() + 40,
defei->GetAimsMonster()->GetX() + (defei->GetAimsMonster()->GetWidth() >> 1),
defei->GetAimsMonster()->GetY() + (defei->GetAimsMonster()->GetHeight() >> 1)) > defei->GetRange())
defei->SetAimsMonster(NULL); //超过距离将目标怪物设为空
}
//防御塔子弹移动
for (auto defei : DefeTowerVec)
defei->BulletMove();
//怪物移动
for (auto Moni = MonsterVec.begin(); Moni != MonsterVec.end(); Moni++)
if((*Moni)->Move()) //怪物走到终点
{
delete *Moni;
MonsterVec.erase(Moni); //怪物走到终点则删除这个怪物
life--; //我们的生命数量-1
lifelable->setText(QString("生命：%1").arg(life));
if (life <= 0) this->close(); //生命值为0时关闭该窗口
break;
}
//判断子弹击中怪物
for (auto defei : DefeTowerVec) //防御塔
{
auto &tbullvec = defei->GetBulletVec(); //临时存储子弹
for (auto bullit = tbullvec.begin(); bullit != tbullvec.end(); bullit++) //子弹
for (auto monit = MonsterVec.begin(); monit != MonsterVec.end(); monit++)//怪物
if ((*bullit)->GetX() + (defei->GetBulletWidth() >> 1) >= (*monit)->GetX() && (*bullit)->GetX() <= (*monit)->GetX() + (*monit)->GetWidth() &&
(*bullit)->GetY() + (defei->GetBulletHeight() >> 1) >= (*monit)->GetY() && (*bullit)->GetY() <= (*monit)->GetY() + (*monit)->GetHeight())
{ //击中怪物时
tbullvec.erase(bullit); //删除子弹
(*monit)->SetHealth((*monit)->GetHealth() - defei->GetAttack()); //敌人血量 = 本身血量减去 当前炮塔攻击力
//将击中的怪物中心的坐标插入到爆炸效果数组
ExploEffectCoor.push_back(new ExploStr(CoorStr((*monit)->GetX() + ((*monit)->GetWidth() >> 1), (*monit)->GetY() + ((*monit)->GetHeight() >> 1)),
defei->GetExplRangeWidth(), defei->GetExplRangeHeight()));
if ((*monit)->GetHealth() <= 0) //生命值为空时
{
//判断一下其他防御塔的目标怪物是否和当前防御塔消灭的怪物重复，如果重复，则将那一个防御塔的目标怪物也设为空
for (auto defei2 : DefeTowerVec)
if (defei2->GetAimsMonster() == *monit)
defei2->SetAimsMonster(NULL);
MonsterVec.erase(monit); //删除怪物
money += RewardMoney; //击败怪物增加金钱
moneylable->setText(QString("金钱：%1").arg(money));//刷新标签
}
//这里不能将防御塔目标怪物设为空，因为防御塔的子弹攻击到的怪物不一定是该防御塔的目标怪物
goto L1;
}
L1:;
}
//显示爆炸效果
for (auto expli = ExploEffectCoor.begin(); expli != ExploEffectCoor.end(); expli++)
{
if((*expli)->index >= 8) //爆炸效果显示完后将该效果从数组中删除
{
ExploEffectCoor.erase(expli);
break;
}
(*expli)->index++; //将要显示的图片的序号++
}
update(); //绘图
});
}
//预设的两条路产生怪物方案
void MainWindow::IrodMonsProgDefa(CoorStr** Waypointarr1, CoorStr** Waypointarr2, CoorStr* staco, int* PathLength, QLabel* victorylable)
{
/*两条路径*/
CoorStr** pointarr[] = {Waypointarr1, Waypointarr2};
/*插入怪物*/
if(counter >= 1 && counter <= 12)
{//插入小恐龙*
InsterMonster(0, 0, 1); //第几条路径、第几个起始点、怪物编号
}
else if(counter > 12 && counter <= 34)
{//在、两路插入小恐龙和鲨鱼
InsterMonster(0, 0, 1);
InsterMonster(1, 1, 2);
}
else if (counter > 34 && counter <= 35)
{//两路插入巨龙
InsterMonster(0, 0, 3);
InsterMonster(1, 1, 3);
}
else if (counter > 35 && counter <= 52)
{//两路插入狮子、狮子、小恐龙
InsterMonster(0, 2, 4);
InsterMonster(0, 0, 4);
InsterMonster(1, 1, 1);
}
if(counter > 52 && counter <= 56)
{//插入巨龙
InsterMonster(0, 0, 3);
InsterMonster(1, 1, 3);
}
if (counter > 52 && counter <= 71)
{//插入鲨鱼、蜗牛、小恐龙、狮子
InsterMonster(0, 2, 2);
InsterMonster(0, 0, 5);
InsterMonster(1, 3, 1);
InsterMonster(1, 1, 4);
}
if (counter > 71 && MonsterVec.empty()) //时间大于71且怪物数组为空时游戏胜利
victorylable->show();
counter++; //计数器+1
update();
}
//根据数组画出地图函数
//由绘图函数调用
void MainWindow::DrawMapArr(QPainter& painter)
{
//地图数组 第一关
int Map_1[16][26] =
{
0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 1, 1, 3, 6, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 1, 1, 6, 6, 0, 0, 0, 0, 0, 0, 3, 6, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 3, 6, 1, 1, 3, 6, 0, 0, 0, 0, 0, 0, 6, 6, 1, 1, 3, 6, 0, 0, 0,
0, 0, 0, 0, 0, 6, 6, 1, 1, 6, 6, 0, 0, 1, 1, 1, 1, 1, 1, 1, 1, 6, 6, 0, 0, 0,
0, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0,
0, 1, 1, 1, 1, 1, 1, 1, 1, 0, 3, 6, 0, 1, 1, 0, 0, 0, 0, 3, 6, 0, 0, 0, 0, 0,
0, 1, 1, 0, 3, 6, 0, 1, 1, 0, 6, 6, 0, 1, 1, 0, 3, 6, 0, 6, 6, 0, 0, 0, 0, 0,
0, 1, 1, 0, 6, 6, 0, 1, 1, 1, 1, 1, 1, 1, 1, 0, 6, 6, 1, 1, 1, 1, 1, 1, 5, 1,
0, 1, 1, 0, 0, 0, 0, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 1, 1, 1, 1, 1, 1, 1, 1,
0, 1, 1, 0, 3, 6, 0, 0, 3, 6, 0, 0, 3, 6, 0, 0, 3, 6, 1, 1, 3, 6, 0, 0, 0, 0,
0, 1, 1, 0, 6, 6, 0, 0, 6, 6, 0, 0, 6, 6, 0, 0, 6, 6, 1, 1, 6, 6, 0, 0, 0, 0,
0, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0, 0,
0, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
};
//第二关
int Map_2[16][26] =
{
0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 1, 1, 3, 6, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 1, 1, 6, 6, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 3, 6, 1, 1, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 6, 6, 1, 1, 0, 0, 3, 6, 0, 1, 1, 0, 0, 3, 6, 0, 0, 3, 6, 0, 0, 0, 0, 0, 0,
0, 0, 0, 1, 1, 0, 0, 6, 6, 0, 1, 1, 0, 0, 6, 6, 0, 0, 6, 6, 0, 0, 0, 0, 0, 0,
0, 0, 0, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 3, 6, 0, 0, 0, 0, 3, 6, 0, 0, 0, 0, 3, 6, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 6, 6, 0, 0, 0, 0, 6, 6, 0, 0, 0, 0, 6, 6, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 5, 1, 3, 6, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 1, 1, 6, 6, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
};
int Map_3[16][26] =
{
0, 0, 0, 0, 0, 3, 6, 1, 1, 1, 1, 5, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 6, 6, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 1, 1, 3, 6, 0, 0, 3, 6, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 1, 1, 6, 6, 0, 0, 6, 6, 1, 1, 3, 6, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 3, 6, 0, 0, 1, 1, 6, 6, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 6, 6, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 1, 1, 3, 6, 0, 0, 3, 6, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 1, 1, 6, 6, 0, 0, 6, 6, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 3, 6, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 6, 6, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 3, 6, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 6, 6, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
};
int Map[16][26]; //用于拷贝不同的关卡数组
switch (LevelNumber)
{
case 0:
memcpy(Map, Map_1, sizeof(Map));
break;
case 1:
memcpy(Map, Map_2, sizeof(Map));
break;
case 2:
memcpy(Map, Map_3, sizeof(Map));
break;
default:
break;
}
for (int j = 0; j < 16; j++)
for (int i = 0; i < 26; i++)
{
switch (Map[j][i])
{
case 0: /*草地*/
painter.drawPixmap(i * 40, j * 40, 40, 40,
QPixmap(":/image/GrassBlock.png"));
break;
case 1: /*地面*/
painter.drawPixmap(i * 40, j * 40, 40, 40,
QPixmap(":/image/GroundBlock.png"));
break;
case 3: /*防御塔坑*/
painter.drawPixmap(i * 40, j * 40, 80, 80,
QPixmap(":/image/StoneBrick.png"));
//防御塔坑坐标初始化塔坑坐标，插入到塔坑对象数组
TowerPitVec.push_back(new DefenseTowerPit(i * 40, j * 40));
break;
case 5: //家在循环中也输出地面
painter.drawPixmap(i * 40, j * 40, 40, 40,
QPixmap(":/image/GroundBlock.png"));
homecoor->x = i * 40, homecoor->y = j * 40;
break;
}
}
painter.drawPixmap(homecoor->x, homecoor->y, 80, 80,
QPixmap(":/image/home.png")); //最后画出家
}
//画出选择框
void MainWindow::DrawSelectionBox(QPainter& painter)
{
//显示选择框
if (!SelBox->GetDisplay())
return;
//画出选择框
painter.drawPixmap(SelBox->GetX(), SelBox->GetY(), SelBox->GetWidth(), SelBox->GetHeight(),
QPixmap(SelBox->GetImgPath()));
//画出子按钮
SubbutStr *ASubBut = SelBox->GetSelSubBut(); //接收子按钮结构数组
for (int i = 0; i < 4; i++)
painter.drawPixmap(ASubBut[i].SubX, ASubBut[i].SubY, ASubBut[i].SubWidth, ASubBut[i].SubHeight,
QPixmap(ASubBut[i].SubImgPath));
painter.setPen(QPen(Qt::yellow, 6, Qt::SolidLine)); //设置画笔
painter.drawRect(QRect(SelBox->GetX() + 95, SelBox->GetY() + 95, 80, 80));
}
//画出防御塔
void MainWindow::DrawDefenseTower(QPainter& painter)
{
//画出防御塔
for (auto defei : DefeTowerVec) //遍历防御塔数组
{
//画出底座
painter.drawPixmap(defei->GetUpLeftX(), defei->GetUpLeftY(), 80, 80, QPixmap(defei->GetBaseImgPath()));
//画出所有防御塔的攻击范围
if(DisplayAllRange)
painter.drawEllipse(QPoint(defei->GetUpLeftX() + 40, defei->GetUpLeftY() + 40), defei->GetRange(), defei->GetRange());
//画出所有防御塔子弹
for (auto bulli : defei->GetBulletVec())
painter.drawPixmap(bulli->coor.x, bulli->coor.y, defei->GetBulletWidth(), defei->GetBulletHeight(),QPixmap(defei->GetBulletPath()));
//画出防御塔
painter.translate(defei->GetUpLeftX() + 40, defei->GetUpLeftY() + 40); //设置旋转中心
painter.rotate(defei->GetRotatAngle()); //旋转角度
painter.translate(-(defei->GetUpLeftX() + 40), -(defei->GetUpLeftY() + 40)); //原点复位
painter.drawPixmap(defei->GetX(), defei->GetY(), defei->GetWidth(), defei->GetHeight(), QPixmap(defei->GetDefImgPath())/*图片路径*/);
painter.resetTransform(); //重置调整
}
}
//画出怪物
void MainWindow::DrawMonster(QPainter& painter)
{
for (auto moni : MonsterVec)//画出怪物
painter.drawPixmap(moni->GetX(), moni->GetY(), moni->GetWidth(), moni->GetHeight(), QPixmap(moni->GetImgPath()));
}
//画出防御塔和升级按钮
void MainWindow::DrawRangeAndUpgrade(QPainter& painter)
{
//根据条件画出防御塔攻击范围和升级按钮
for (auto defei : DefeTowerVec)
if(defei->GetUpLeftX() == DisplayRangeX && defei->GetUpLeftY() == DisplayRangeY && DisplayRange)
{ //画出防御塔攻击范围
painter.setPen(QPen(Qt::red)); //使用红色画出范围
painter.drawEllipse(QPoint(DisplayRangeX + 40, DisplayRangeY + 40), defei->GetRange(), defei->GetRange());
painter.drawPixmap(DisplayRangeX + 10, DisplayRangeY - 80, 60, 60, QPixmap(":/image/UpgradeBut1.png"));
}
}
//画出爆炸效果
void MainWindow::DrawExplosion(QPainter& painter)
{
//显示所有爆炸效果
for (auto expli : ExploEffectCoor)
painter.drawPixmap(expli->coor.x - (expli->ExplRangeWidth >> 1), expli->coor.y - (expli->ExplRangeHeight >> 1),
expli->ExplRangeWidth, expli->ExplRangeHeight, QPixmap(QString(":/image/ExplosionEffect%1.png").arg(expli->index)));
}
//绘图事件
void MainWindow::paintEvent(QPaintEvent *)
{
QPainter painter(this); //创建画家类
painter.setRenderHint(QPainter::Antialiasing); //设置抗锯齿
DrawMapArr(painter); //画出地图
DrawDefenseTower(painter); //画出防御塔和子弹
DrawMonster(painter); //画出怪物
DrawRangeAndUpgrade(painter);//画出攻击范围和升级按钮
DrawExplosion(painter); //画出爆炸效果
DrawSelectionBox(painter); //画出选择框
}
//鼠标点击事件
void MainWindow::mousePressEvent(QMouseEvent *ev)
{
if (ev->button() != Qt::LeftButton)
return;
//判断升级按钮的点击
if (DisplayRange)
{
if (MouClickRegion(DisplayRangeX + 10, 60 , DisplayRangeY - 80, 60))
{
//设置防御塔宽高，攻击力，微调坐标
for (auto defei : DefeTowerVec)
if (defei->GetUpLeftX() == DisplayRangeX && defei->GetUpLeftY() == DisplayRangeY && DisplayRange)
{
if (DeductionMoney(200)) return; //升级防御塔需要花费200
defei->SetAttack(defei->GetAttack() + 20); //每次升级防御塔攻击力+20
defei->SetWidthHeight(defei->GetWidth() + 12, defei->GetHeight() + 6); //防御塔宽高增加
defei->SetXY(defei->GetX() - 6, defei->GetY() - 3); //调整防御塔坐标
defei->SetAimsMonster(NULL); //将防御塔目标设为空
defei->SetRange() += 14; //设置防御塔的攻击范围
defei->SetExplRangeWidthHeight(defei->GetExplRangeWidth() + 5, defei->GetExplRangeHeight() + 5); //设置防御塔攻击怪物所产生的爆炸效果宽高
defei->SetBulletWidthHeight(defei->GetBulletWidth() + 5, defei->GetBulletHeight() + 5); //设置子弹宽高
break;
}
SelBox->SetDisplay(false); //取消显示新建防御塔框
DisplayRange = false; //取消显示自己
update();
return;
}
}
//判断选择框四个子按钮的点击
SubbutStr *ASubBut = SelBox->GetSelSubBut();
for (int i = 0; i < 4; i++)
if (MouClickRegion(ASubBut[i].SubX, ASubBut[i].SubWidth, ASubBut[i].SubY, ASubBut[i].SubHeight) && SelBox->GetDisplay())
{
SelBox->SetDisplay(false); //取消显示选择框
//根据点击的不同的按钮，将防御塔子类插入到防御塔父类数组
switch (i)
{
case 0: //绿瓶
if (DeductionMoney(100)) return; //扣除金钱
DefeTowerVec.push_back(new GreenTurret(SelBox->GetX() + 110, SelBox->GetY() + 112, SelBox->GetX() + 95, SelBox->GetY() + 95, 72, 46));
break;
case 1: //火瓶
if (DeductionMoney(160)) return;
DefeTowerVec.push_back(new FireTurret(SelBox->GetX() + 110, SelBox->GetY() + 112, SelBox->GetX() + 95, SelBox->GetY() + 95, 72, 46));
break;
case 2: //光炮
if (DeductionMoney(240)) return;
DefeTowerVec.push_back(new LightTurret(SelBox->GetX() + 110, SelBox->GetY() + 112, SelBox->GetX() + 95, SelBox->GetY() + 95, 76, 50));
break;
case 3: //大炮
if (DeductionMoney(400)) return;
DefeTowerVec.push_back(new BigTurret(SelBox->GetX() + 110, SelBox->GetY() + 104, SelBox->GetX() + 95, SelBox->GetY() + 95, 80, 70));
break;
default:
break;
}
update();
return;
}
//遍历所有塔坑
for (auto APit : TowerPitVec)
//判断点击塔坑
if (MouClickRegion(APit->GetX(), APit->GetWidth(), APit->GetY(), APit->GetHeight()))
{
DisplayRange = false; //降防御塔的升级选择显示关闭
for (auto defei : DefeTowerVec) //遍历数组判断防御塔坐标和点击坑坐标重合则返回
if(defei->GetUpLeftX() == APit->GetX() && defei->GetUpLeftY() == APit->GetY())
{
DisplayRangeX = defei->GetUpLeftX(), DisplayRangeY = defei->GetUpLeftY(); //记录要显示攻击范围的防御塔的坐标
DisplayRange = true; //显示防御塔攻击范围
return;
}
SelBox->CheckTower(APit->GetX(), APit->GetY()); //选中防御塔，选择框显示
update();
return;
}
DisplayRange = false; //取消显示防御塔攻击范围
SelBox->SetDisplay(false); //取消显示选择框
update();
}
//鼠标移动事件 测试炮台旋转
//void MainWindow::mouseMoveEvent(QMouseEvent *ev)
//{
// for(auto defei : DefeTowerVec)
// defei->SetRotatAngle(atan2(ev->y() - defei->GetUpLeftY() + 40, ev->x() - defei->GetUpLeftX()) * 180 / 3.1415); //计算炮塔旋转的度数
// update();
//}
//析构释放内存
MainWindow::~MainWindow()
{
//释放防御塔坑指针数组TowerPitVec
for (auto it = TowerPitVec.begin(); it != TowerPitVec.end(); it++)
{
delete *it;
*it = NULL;
}
//释放选择框类SelBox
delete SelBox;
SelBox = NULL;
//释放防御塔父类指针数组DefeTowerVec
for (auto it = DefeTowerVec.begin(); it != DefeTowerVec.end(); it++)
{
delete *it;
*it = NULL;
}
//释放怪物数组MonsterVec
for (auto it = MonsterVec.begin(); it != MonsterVec.end(); it++)
{
delete *it;
*it = NULL;
}
//释放爆炸效果指针数组ExploEffectCoor
for (auto it = ExploEffectCoor.begin(); it != ExploEffectCoor.end(); it++)
{
delete *it;
*it = NULL;
}
delete homecoor;
}
#ifndef MONSTER_H
#define MONSTER_H
#include <QVector>
#include <QString>
#include "globalstruct.h" //坐标结构
//怪物类
class Monster
{
private:
QVector<CoorStr*> Waypoint; //存储怪物路径点数组
int mx, my; //怪物坐标
int mwidth, mheight; //怪物宽高
QString ImgPath; //怪物图片路径
int id; //怪物编号
int health; //怪物生命值
int mspeed = 10; //怪物移动速度
public:
//参数：路径点数组、路径点的个数、怪物初始坐标、怪物宽度、怪物图片路径
Monster(CoorStr **pointarr, int arrlength, int x, int y, int fid); //构造
bool Move(); //怪物移动函数
int GetX() const; //获取横坐标
int GetY() const; //获取横坐标
int GetWidth() const; //获取宽
int GetHeight() const; //获取高
QString GetImgPath() const; //获取图片路径
int GetId() const; //获取编号
int GetHealth() const; //获取生命值
void SetHealth(int); //设置生命值
};
#endif // MONSTER_H
#include "monster.h"
#include <QDebug>
//怪物类函数实现
Monster::Monster(CoorStr **pointarr, int arrlength, int x, int y, int fid) :
mx(x), my(y), id(fid)
{
for(int i = 0; i < arrlength; i++) //将传进来的数组插入到Waypoint动态数组
Waypoint.push_back(pointarr[i]);
//确定不同怪物的生命值
switch (id)
{
case 1: //小恐龙怪1
health = 100; //生命值
mwidth = 64, mheight = 64; //宽高
ImgPath = "C:/Users/ASUS/Desktop/image/怪物1.png";
break;
case 2: //鱼怪2
health = 120;
mwidth = 86, mheight = 64;
ImgPath = "C:/Users/ASUS/Desktop/image/怪物2.png";
break;
case 3: //飞龙怪3
health = 650;
mwidth = 160, mheight = 120;
ImgPath = "C:/Users/ASUS/Desktop/image/怪物3.png";
break;
case 4: //狮子怪4
health = 310;
mwidth = 98, mheight = 70;
ImgPath = "C:/Users/ASUS/Desktop/image/怪物4.png";
break;
case 5: //蜗牛怪5
health = 200;
mwidth = 90, mheight = 76;
ImgPath = "C:/Users/ASUS/Desktop/image/怪物5.png";
break;
default:
break;
}
}
//怪物按设定路径点移动
bool Monster::Move()
{
if(Waypoint.empty())
return true;
//如果第一个路径点的y小于怪物原本的路径点，则怪物向下走
if (Waypoint.at(0)->y > my) //下
{
my += mspeed;
return false;
}
if (Waypoint.at(0)->x < mx) //左
{
mx -= mspeed;
return false;
}
if (Waypoint.at(0)->x > mx) //右
{
mx += mspeed;
return false;
}
if (Waypoint.at(0)->y < my) //上
{
my -= mspeed;
return false;
}
//如果怪物的坐标和路径点坐标几乎重合，则删除这个路径点
// if (Waypoint.at(0)->y >= my && Waypoint.at(0)->y <= my + 14 && Waypoint.at(0)->x >= mx && Waypoint.at(0)->x <= mx + 14)
if (Waypoint.at(0)->y == my && Waypoint.at(0)->x == mx)
{
delete Waypoint.begin(); //释放坐标点内存
Waypoint.erase(Waypoint.begin()); //从数组中删除
// return false;
}
return false;
}
int Monster::GetX() const //获取横坐标
{
return mx;
}
int Monster::GetY() const //获取横坐标
{
return my;
}
int Monster::GetWidth() const //获取宽
{
return mwidth;
}
int Monster::GetHeight() const //获取高
{
return mheight;
}
QString Monster::GetImgPath() const //获取图片路径
{
return ImgPath;
}
int Monster::GetId() const //获取编号
{
return id;
}
int Monster::GetHealth() const //获取生命值
{
return health;
}
void Monster::SetHealth(int fhealth)//设置生命值
{
health = fhealth;
}
更多精彩推荐
☞云上容器 ATT&CK 矩阵详解，阿里云助力企业容器化安全落地
☞秋名山老司机从上车到翻车的悲痛经历，带你深刻了解什么是 Spark on Hive！| 原力计划
![]()
你点的每个“在看”，我都认真当成了喜欢
登录查看更多
相关内容
TACO:ACM Transactions on Architecture and Code Optimization。
Explanation：架构和代码优化的ACM事务。
Publisher：ACM。
SIT：http://dblp.uni-trier.de/db/journals/taco/
Arxiv
33+阅读 · 2019年10月24日
相关VIP内容
相关资讯
相关论文
Arxiv
33+阅读 · 2019年10月24日
微信扫码咨询专知VIP会员
